Label in the center of each line with the text

[Designer68]

Hello





Is there a way (lisp) to label lines. I want to draw multiple lines (buildings) and i need a label in the center of each line with the text Left or Right.

Based on the location of the previous line.



if possible starting clockwise and counter clockwise as well.





[SLW210]

I have moved your thread to the AutoLISP, Visual LISP & DCL Forum. Please post in the correct forum.

[mhupp]

Its best to upload a sample drawing of what your looking to do.

[Designer68]

This is the example. Start point and toen above ech line if i went left or right.

The most drawings i have to make are counterclockwise.





[mhupp]

Made this for someone a couple of months ago. They would import a satellite photo and they wanted to pick the corners of the house.



;;----------------------------------------------------------------------------;;
;; L Shape House
(defun C:LHouse (/ p1 p2 p3 p4 p5 p6)
  (setq p1 (getpoint "\nPick Point 1")
        p2 (getpoint "\nPick Point 2")
        p3 (getpoint "\nPick Point 3")
        p4 (getpoint "\nPick Point 4")
        p5 (getpoint "\nPick Point 5")
  )
  (setq p6 (list (car p5) (cadr p1)))
  (setvar 'cmdecho 0)
  (command "_.pline" "_non" p1 "_non" p2 "_non" p3 "_non" p4 "_non" p5 "_non" p6 "_CL")
  (setvar 'cmdecho 1)
  (princ)
)



Don't know about the L or R's

[BIGAL]

If you draw a pline of picked points and close as normal, then get vertices/co-ordinates you can determine using say pt1 pt2 pt3 angle, is it L or R then label etc the last leg is like angle pt6 pt1 pt2 you should label leg 1-2 need time to think.

[Designer68]

11 hours ago, mhupp said:





11 hours ago, mhupp said:





Edited December 14, 2021 by Designer68

[Designer68]

Thanks for the lisp, i will look if it works for me.



Jan Pieter

Edited December 14, 2021 by Designer68

[Designer68]

9 hours ago, BIGAL said:

If you draw a pline of picked points and close as normal, then get vertices/co-ordinates you can determine using say pt1 pt2 pt3 angle, is it L or R then label etc the last leg is like angle pt6 pt1 pt2 you should label leg 1-2 need time to think.

Bigal,



Pt 1 Pt2 needs no label, because it is from the startpoint. So the label starts between 2 and 3

[SLW210]

I have renamed your thread to "Label in the center of each line with the text". Please use descriptive titles.

[BIGAL]

There is better examples of this as many points as you want Close is supported but still need a enter to stop, busy today so sorry no code time.



(defun c:plpts ( / pt)
(setq pt (getpoint "\nStarting point of Pline : "))
(command-s "_.pline" pt)
(while (getpoint "\nPick next pt Enter to stop") )
)
