whosa Posted November 30, 2016 Posted November 30, 2016 Hi, I would like to add the doors through Lisp. I would like to add automatically something like the picture attached (yellow doors block). Thanks in advance Santo Quote
ReMark Posted November 30, 2016 Posted November 30, 2016 (edited) Is the block going to be inserted on any particular layer? If so, does the layer exist or does it have to be created? How many different door blocks do you have? Will the block have to be scaled? Where are the blocks located? Have you given any thought to creating a tool palette and populating it with your most commonly used blocks? Then you can drag and drop the blocks rather than inserting via a lisp program. Edited November 30, 2016 by ReMark Quote
whosa Posted November 30, 2016 Author Posted November 30, 2016 I have just one door block and i scale/orientate it each time. The layer is on the dwg block It is a consistent time consuming. I would like to have something like: 1st click: at the beginning of the door 2nd click: end of the doors 3rd click: orientation the block is attached on this post [ATTACH]59979[/ATTACH] Quote
ReMark Posted November 30, 2016 Posted November 30, 2016 One block? Put it on a tool palette. Easiest and quickest solution. Quote
whosa Posted November 30, 2016 Author Posted November 30, 2016 Yes, I have it on the tool palette. The ploblem is I have to scale and orientate it each time Quote
ReMark Posted November 30, 2016 Posted November 30, 2016 Are you're drawings done to full size or are they drawn "to scale" as one might do on a drafting board? BTW...your attachment above is invalid (i.e. - no good). Quote
whosa Posted November 30, 2016 Author Posted November 30, 2016 Full scale. bit the door opening/orientation are different and i need to adapt the block each time. door.dwg Quote
Grrr Posted November 30, 2016 Posted November 30, 2016 (edited) Daily practice: [color=#8b4513]; Block on Line, Grrr[/color] [b][color=BLACK]([/color][/b]defun C:test [color=#8b4513];| credits to: Lee Mac |; [b][color=FUCHSIA]([/color][/b] / b bn p e [b][color=FUCHSIA])[/color][/b][/color] [b][color=FUCHSIA]([/color][/b]setvar 'errno 0[b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]while [b][color=NAVY]([/color][/b]/= 52 [b][color=MAROON]([/color][/b]getvar 'errno[b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]setq b [b][color=MAROON]([/color][/b]car [b][color=GREEN]([/color][/b]entsel [color=#2f4f4f]"\nSelect block to reinsert <exit>: "[/color][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]cond [b][color=MAROON]([/color][/b] [b][color=GREEN]([/color][/b]= 7 [b][color=BLUE]([/color][/b]getvar 'errno[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]princ [color=#2f4f4f]"\nMissed, try again."[/color][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]setvar 'errno 0[b][color=GREEN])[/color][/b] [b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b] [b][color=GREEN]([/color][/b]and [b][color=BLUE]([/color][/b]= 'ENAME [b][color=RED]([/color][/b]type b[b][color=RED])[/color][/b][b][color=BLUE])[/color][/b] [b][color=BLUE]([/color][/b]/= [b][color=RED]([/color][/b]cdr [b][color=PURPLE]([/color][/b]assoc 0 [b][color=TEAL]([/color][/b]entget b[b][color=TEAL])[/color][/b][b][color=PURPLE])[/color][/b][b][color=RED])[/color][/b] [color=#2f4f4f]"INSERT"[/color][b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]princ [color=#2f4f4f]"\nThis is not a block."[/color][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]setq b nil[b][color=GREEN])[/color][/b] [b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]b [b][color=GREEN]([/color][/b]setq bn [b][color=BLUE]([/color][/b]vla-get-EffectiveName [b][color=RED]([/color][/b]vlax-ename->vla-object b[b][color=RED])[/color][/b][b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]while [b][color=BLUE]([/color][/b]/= 52 [b][color=RED]([/color][/b]getvar 'errno[b][color=RED])[/color][/b][b][color=BLUE])[/color][/b] [b][color=BLUE]([/color][/b]and [b][color=RED]([/color][/b]setq p [b][color=PURPLE]([/color][/b]getpoint [color=#2f4f4f]"\nSelect a line to insert on it: <exit>"[/color][b][color=PURPLE])[/color][/b][b][color=RED])[/color][/b] [b][color=RED]([/color][/b]setq e [b][color=PURPLE]([/color][/b]car [b][color=TEAL]([/color][/b]nentselp p[b][color=TEAL])[/color][/b][b][color=PURPLE])[/color][/b][b][color=RED])[/color][/b] [b][color=BLUE])[/color][/b] [b][color=BLUE]([/color][/b]cond [b][color=RED]([/color][/b][b][color=PURPLE]([/color][/b]not p[b][color=PURPLE])[/color][/b] [b][color=PURPLE]([/color][/b]setvar 'errno 52[b][color=PURPLE])[/color][/b] [b][color=RED])[/color][/b] [b][color=RED]([/color][/b][b][color=PURPLE]([/color][/b]not e[b][color=PURPLE])[/color][/b] [b][color=PURPLE]([/color][/b]princ [color=#2f4f4f]"\nMissed, try again."[/color][b][color=PURPLE])[/color][/b] [b][color=RED])[/color][/b] [b][color=RED]([/color][/b] [b][color=PURPLE]([/color][/b]and p [b][color=TEAL]([/color][/b]vl-catch-all-error-p [b][color=OLIVE]([/color][/b]vl-catch-all-apply 'vlax-curve-getFirstDeriv [b][color=GRAY]([/color][/b]list e [b][color=AQUA]([/color][/b]vl-catch-all-apply 'vlax-curve-getParamAtPoint [b][color=LIME]([/color][/b]list e p[b][color=LIME])[/color][/b][b][color=AQUA])[/color][/b][b][color=GRAY])[/color][/b][b][color=OLIVE])[/color][/b] [b][color=TEAL])[/color][/b] [b][color=PURPLE])[/color][/b] [b][color=PURPLE]([/color][/b]princ [color=#2f4f4f]"\nThis object is not a curve."[/color][b][color=PURPLE])[/color][/b] [b][color=RED])[/color][/b] [b][color=RED]([/color][/b]T [b][color=PURPLE]([/color][/b]and bn p e [b][color=TEAL]([/color][/b]vla-InsertBlock [b][color=OLIVE]([/color][/b]vlax-get-property [b][color=GRAY]([/color][/b]vla-get-ActiveDocument [b][color=AQUA]([/color][/b]vlax-get-acad-object[b][color=AQUA])[/color][/b][b][color=GRAY])[/color][/b] [b][color=GRAY]([/color][/b]if [b][color=AQUA]([/color][/b]= 1 [b][color=LIME]([/color][/b]getvar 'CVPORT[b][color=LIME])[/color][/b][b][color=AQUA])[/color][/b] 'Paperspace 'Modelspace[b][color=GRAY])[/color][/b] [b][color=OLIVE])[/color][/b] [color=#8b4513]; AcSpc[/color] [b][color=OLIVE]([/color][/b]vlax-3D-point p[b][color=OLIVE])[/color][/b] bn 1. 1. 1. [b][color=OLIVE]([/color][/b]alg-ang e p[b][color=OLIVE])[/color][/b] [b][color=TEAL])[/color][/b] [b][color=TEAL]([/color][/b]setvar 'errno 52[b][color=TEAL])[/color][/b] [b][color=PURPLE])[/color][/b] [b][color=RED])[/color][/b] [b][color=BLUE])[/color][/b] [b][color=GREEN])[/color][/b] [b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]T nil[b][color=MAROON])[/color][/b] [b][color=NAVY])[/color][/b][color=#8b4513]; cond[/color] [b][color=FUCHSIA])[/color][/b][color=#8b4513]; while[/color] [b][color=FUCHSIA]([/color][/b]princ[b][color=FUCHSIA])[/color][/b] [b][color=BLACK])[/color][/b][color=#8b4513];| defun |; [b][color=BLACK]([/color][/b]vl-load-com[b][color=BLACK])[/color][/b] [b][color=BLACK]([/color][/b]princ[b][color=BLACK])[/color][/b][/color] [color=#8b4513]; BIGAL's example of [color=#2f4f4f]"vlax-curve-getFirstDeriv"[/color] usage:[/color] [b][color=BLACK]([/color][/b]defun alg-ang [b][color=FUCHSIA]([/color][/b]obj pnt[b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]angle '[b][color=NAVY]([/color][/b]0. 0. 0.[b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]vlax-curve-getFirstDeriv obj [b][color=MAROON]([/color][/b]vlax-curve-getParamAtPoint obj pnt[b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=FUCHSIA])[/color][/b] [b][color=BLACK])[/color][/b][color=#8b4513]; defun[/color] Edited November 30, 2016 by Grrr Quote
whosa Posted November 30, 2016 Author Posted November 30, 2016 This lisp is just for orientations, not for scale. Is not helpful in my case. Attached I add a new version of the block whit parameter Rotate - Scale - Flip door_smart.dwg Quote
Grrr Posted November 30, 2016 Posted November 30, 2016 Are you aware of the align command? It just expects 4 points, enter and Yes or No for scale. Quote
whosa Posted November 30, 2016 Author Posted November 30, 2016 I used align .... If the door are few it is ok... When i Need to add 60 different door it is a time consuming . I made a dinamic bock but is still a slow method Quote
Grrr Posted November 30, 2016 Posted November 30, 2016 I used align .... If the door are few it is ok... When i Need to add 60 different door it is a time consuming . I made a dinamic bock but is still a slow method This might help: (defun C:test ;| credits to: Lee Mac |; ( / *error* cm SelBname bn p Blk ll ur msg SS cen Grrr mc ) (defun *error* (m) (redraw)(and cm (setvar 'cmdecho cm)) (and m (print m)) (princ)) (defun SelBname ( / e bn ) (setvar 'errno 0) (while (/= 52 (getvar 'errno)) (setq e (car (entsel "\nSelect block to reinsert <exit>: "))) (cond ( (= 7 (getvar 'errno)) (princ "\nMissed, try again.") (setvar 'errno 0) ) ( (and (= 'ENAME (type e)) (/= (cdr (assoc 0 (entget e))) "INSERT")) (princ "\nThis is not a block.") (setq e nil) ) ( (and e (not (alert "Visit lee-mac.com")) (setq bn (vla-get-EffectiveName (vlax-ename->vla-object e))) (setvar 'errno 52)) ) ); cond ); while bn ); defun SelBname (redraw) (setq bn (SelBname)) (while (and (setq cm (getvar 'cmdecho)) (setvar 'cmdecho 0) bn (last (setq p (list (getpoint "\nSpecify insertion point <exit>: ")))) (last (setq p (append p (list (getpoint (last p) "\nSpecify second point <exit>: "))))) (not (apply 'grdraw (append p (list 1 7)))) (setq Blk (vla-InsertBlock (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object)) (if (= 1 (getvar 'CVPORT)) 'Paperspace 'Modelspace) ) ; AcSpc (vlax-3D-point (car p)) bn 1. 1. 1. 0. ) ) ) (progn (vla-GetBoundingBox Blk 'll 'ur) (vla-ScaleEntity Blk (vlax-3D-point (car p)) (/ (apply 'distance p) (abs (apply '- (mapcar 'car (mapcar 'vlax-safearray->list (list ll ur))))) ) ) (vla-put-Rotation Blk (apply 'angle p)) (setq msg "\nPress [TAB] to change orientation, [ENTER] to exit: ") (and msg (princ msg)) (setvar 'errno 0) (setq SS (ssadd)) (ssadd (handent (vla-get-Handle Blk)) SS) (setq cen (apply 'mapcar (cons '(lambda (a b) (/ (+ a b) 2.)) p))) (while (/= 52 (getvar 'errno)) (setq Grrr (grread T)) (cond ((= (car Grrr) 2) (cond ((= (cadr Grrr) (ascii "\t")) (and msg (princ msg)) (and (not mc) (setq mc 0)) (setq mc (rem (+ mc 1) 4)) (cond ( (or (= mc 1) (= mc 3) ) (command "_.MIRROR" SS "" "_non" cen "_non" (polar cen (+ (apply 'angle p) (/ PI 2.)) (apply 'distance p)) "_Y") ) ( (or (= mc 2) (= mc 0) ) (command "_.MIRROR" SS "" "_non" cen "_non" (polar cen (apply 'angle p) (apply 'distance p)) "_Y") ) ) ) ((= (cadr Grrr) (ascii "\r")) (princ "\nExiting.") (redraw) (setvar 'errno 52) ) ); cond ) ((= (car Grrr) 25) (princ "\nExiting.") (redraw) (setvar 'errno 52) ) ); cond ); while ); progn ); while/if (and cm (setvar 'cmdecho cm)) (princ) );| defun |; (vl-load-com) (princ) You just need to specify 2 points, hit Tab key and Enter when done. Quote
BIGAL Posted December 1, 2016 Posted December 1, 2016 If you have a look at this image its done by slicing out a section of the wall and then inserting the door details all in 2D+. The width is just input. Its asks for a start point and a direction swing in or out draws the door jamb. Now its copy righted so no code but the total package still exists if you want more info send me a PM. If I was to redo this task I would use a dynamic block door so much easier to resize. Quote
whosa Posted December 1, 2016 Author Posted December 1, 2016 This might help: (defun C:test ;| credits to: Lee Mac |; ( / *error* cm SelBname bn p Blk ll ur msg SS cen Grrr mc ) (defun *error* (m) (redraw)(and cm (setvar 'cmdecho cm)) (and m (print m)) (princ)) (defun SelBname ( / e bn ) (setvar 'errno 0) (while (/= 52 (getvar 'errno)) (setq e (car (entsel "\nSelect block to reinsert <exit>: "))) (cond ( (= 7 (getvar 'errno)) (princ "\nMissed, try again.") (setvar 'errno 0) ) ( (and (= 'ENAME (type e)) (/= (cdr (assoc 0 (entget e))) "INSERT")) (princ "\nThis is not a block.") (setq e nil) ) ( (and e (not (alert "Visit lee-mac.com")) (setq bn (vla-get-EffectiveName (vlax-ename->vla-object e))) (setvar 'errno 52)) ) ); cond ); while bn ); defun SelBname (redraw) (setq bn (SelBname)) (while (and (setq cm (getvar 'cmdecho)) (setvar 'cmdecho 0) bn (last (setq p (list (getpoint "\nSpecify insertion point <exit>: ")))) (last (setq p (append p (list (getpoint (last p) "\nSpecify second point <exit>: "))))) (not (apply 'grdraw (append p (list 1 7)))) (setq Blk (vla-InsertBlock (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object)) (if (= 1 (getvar 'CVPORT)) 'Paperspace 'Modelspace) ) ; AcSpc (vlax-3D-point (car p)) bn 1. 1. 1. 0. ) ) ) (progn (vla-GetBoundingBox Blk 'll 'ur) (vla-ScaleEntity Blk (vlax-3D-point (car p)) (/ (apply 'distance p) (abs (apply '- (mapcar 'car (mapcar 'vlax-safearray->list (list ll ur))))) ) ) (vla-put-Rotation Blk (apply 'angle p)) (setq msg "\nPress [TAB] to change orientation, [ENTER] to exit: ") (and msg (princ msg)) (setvar 'errno 0) (setq SS (ssadd)) (ssadd (handent (vla-get-Handle Blk)) SS) (setq cen (apply 'mapcar (cons '(lambda (a b) (/ (+ a b) 2.)) p))) (while (/= 52 (getvar 'errno)) (setq Grrr (grread T)) (cond ((= (car Grrr) 2) (cond ((= (cadr Grrr) (ascii "\t")) (and msg (princ msg)) (and (not mc) (setq mc 0)) (setq mc (rem (+ mc 1) 4)) (cond ( (or (= mc 1) (= mc 3) ) (command "_.MIRROR" SS "" "_non" cen "_non" (polar cen (+ (apply 'angle p) (/ PI 2.)) (apply 'distance p)) "_Y") ) ( (or (= mc 2) (= mc 0) ) (command "_.MIRROR" SS "" "_non" cen "_non" (polar cen (apply 'angle p) (apply 'distance p)) "_Y") ) ) ) ((= (cadr Grrr) (ascii "\r")) (princ "\nExiting.") (redraw) (setvar 'errno 52) ) ); cond ) ((= (car Grrr) 25) (princ "\nExiting.") (redraw) (setvar 'errno 52) ) ); cond ); while ); progn ); while/if (and cm (setvar 'cmdecho cm)) (princ) );| defun |; (vl-load-com) (princ) You just need to specify 2 points, hit Tab key and Enter when done. I received this error bad argument type: numberp: # Quote
Grrr Posted December 1, 2016 Posted December 1, 2016 I received this error bad argument type: numberp: # Thats weird, everything works fine on my end. You could provide some assitance by following this tutorial to figure out where did the code fail. Quote
