subbarayalusanthanam Posted December 5, 2013 Posted December 5, 2013 how to draw 2D helical gear drawing in Autocad:shock: Quote
ReMark Posted December 5, 2013 Posted December 5, 2013 Just to be clear, you want to draw a helical gear in 2D and not an involute gear. Is that correct? I think the best way to draw a 2D helical gear would be in an isometric view. Quote
subbarayalusanthanam Posted December 5, 2013 Author Posted December 5, 2013 yes, helical gear in 2D drawing Quote
ReMark Posted December 5, 2013 Posted December 5, 2013 (edited) Well what information do you have to work with? Let's see it. If you are going to pause for a long period of time before replying to a post this is going to take much longer than it should. Edited December 5, 2013 by ReMark Quote
ReMark Posted December 5, 2013 Posted December 5, 2013 Disclaimer: I don't draw gears for a living. This is what I think a 2D helical gear might look like in plan and side view. Hidden lines shown in blue. Quote
ReMark Posted December 5, 2013 Posted December 5, 2013 An example of a 3D helical gear. This one is different than the 2D version posted previously as there is slightly more twist to it. Quote
subbarayalusanthanam Posted December 14, 2013 Author Posted December 14, 2013 thanks for your reply Quote
ReMark Posted December 14, 2013 Posted December 14, 2013 You're entirely welcomed. Post an image of your drawing when you are done. We'd like to see it. Quote
rataylor Posted January 6, 2014 Posted January 6, 2014 use my tutorials to draw in Inventor, create the idw file , then save it as an autocad dwg. how to draw 2D helical gear drawing in Autocad:shock: Quote
