imksa Posted June 12, 2013 Share Posted June 12, 2013 Dimension elements do not appear clear on the screen I want to Imaging the screen to use the image in another place How do I make the dimensions clear ? http://www.mediafire.com/download/4flfn5fua01n815/60.dwg Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2013 Share Posted June 12, 2013 Are you using an Arial font? Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2013 Share Posted June 12, 2013 Tried to download your drawing but this is as far as I could get. Quote Link to comment Share on other sites More sharing options...
imksa Posted June 12, 2013 Author Share Posted June 12, 2013 Are you using an Arial font? Yes, and try with other fonts with the same result, the default font slim and unclear Tried to download your drawing but this is as far as I could get. Sorry Now drawing became public Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2013 Share Posted June 12, 2013 And you are creating an image file to use elsewhere? This isn't a matter of printing to a PDF is it? Are your dimensions in model space or paper space? Quote Link to comment Share on other sites More sharing options...
eldon Posted June 12, 2013 Share Posted June 12, 2013 Perhaps this is one case when the old AutoCAD .shx font is better than a TTF one. This image with Romans font Quote Link to comment Share on other sites More sharing options...
nestly Posted June 12, 2013 Share Posted June 12, 2013 Anti-aliasing for True Type fonts is disabled in AutoCAD when dimensions are not at 0 elevation and/or displayed in a 3D visual style. There is no solution other than switching to a shx font as stated above. Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2013 Share Posted June 12, 2013 Note to OP: Your dimensions need some work. Some of them are not reading in the right direction and two of them actually touch each other. Quote Link to comment Share on other sites More sharing options...
imksa Posted June 12, 2013 Author Share Posted June 12, 2013 Well i do the following to resolve the problem: - 1 - tried to raise the level of drawing for Dimension 14 10 16 because it apparently inside the body 2 - tried to enlarge numbers seems clearer But the dimensional overlapped each other. 3 - Drawing paper is usually rcopy multiple times and not From the original so rapidly less quality 4 - I need the image In image format (jpg, bmb, ..) and not pdf dimensions in model space I'm trying to make dimensional read in two directions left & top Quote Link to comment Share on other sites More sharing options...
