Convex fillet???

[Tom Nikitas]

Have placed a cylinder on top of a rectangle. E&W/0°,270° are tangent to rectangle's edge(s) .............rectangle extends beyond 6&12.



Have radiused the corners of the rectangle but am not making the fillet work at the juncture of the cyl and rectangle.



Tried multiple times, doing best to follow commands/requests but no joy. I did on several occasions end up with what I can best describe as the radius running inward toward the cyl's C/L........therefore my "convex" description. The opposite of the desired weld type fillet.



What's with the small white sq and the overlayed, larger blue squares?



Am working my way thru the tutorials but haven't hit this one yet.

Edited May 5, 2011 by Tom Nikitas
Sq's.

[JD Mather]

Attach the file here.

[Tom Nikitas]

Extreme regrets Mr Mather, I don't know how to do that..........yet.



When I said rectangle, it is an extrusion. I changed my UCS every which way from Sunday in case I was getting hung up there, nada.

[SLW210]

To add your file...Go Advanced>Manage Attachments>Choose File>Upload>Close window.

[CyberAngel]

If you can't get a fillet to work in a particular location, you may get Circle TTR to work. Start the Circle command, type T, pick two objects, and input your radius. The resulting circle will be tangent to both objects.



Assuming that doesn't work, can you at least post a screen shot? In these situations, a picture really is worth a thousand words.

[JD Mather]

... In these situations, a picture really is worth a thousand words.



...and a file is worth

[SLW210]

...and a file is worth



....a thousand pictures.

[JD Mather]

Have placed a cylinder on top of a rectangle.



Cylinder and box. Did you Union them before attempting fillet?

[Tom Nikitas]

"Monission.........??? I must be fried - had the final this week.





I failed (in a semi epic manner) to union.



My appreciation for all that posted.



What is going on is one student, me, with maybe a "B" worth of smarts starting with 3D w/o any prior knowledge of CAD. After having just finished my first class of 3D, looking back, my analogy is that of one trying to do Algebra w/o knowing the times tables and NEVER being given ANY of the times tables to learn while trying to keep the head bone above the murky brine.



I'm sure the instructor is/was an absolute whizz in industry (20 yrs experience) but with little to no ability to gear his thinking to a stone beginner, after interviewing the beginner before signing up..........No harm other than a LOT of stress, short days at work (reduced pay check) and a tutor's expense. Kinda grabbing hold of a raging bull and just trying to survive the ride. Some bruises, lotz of dust flew and still scrambling trying to fill in the voids - and there are plenty of them.



Working on pedit at this time. Not making much headway yet but have this w/e to try and get that l'il dragon slayed (slew?).



Again, my thanks to all.

Edited May 7, 2011 by Tom Nikitas
Monission??????????? Sheesh, I must be fried.....
