e.mounir Posted December 27, 2009 Share Posted December 27, 2009 Hi all i have new project , we make the shop drawing for it . The problem is all object in the file (line, circle, pline, rectangle ….etc. ) this in all files , I want make every thing (Z=0) I used AUTOCAD2009 Marry Christmas for all of you Quote Link to comment Share on other sites More sharing options...
CarlB Posted December 27, 2009 Share Posted December 27, 2009 To make existing objects have z=0, try the "flatten" command. if command not recognized, you may have to install Express Tools, from the installation disk. Another option is a lisp routine to do this, such as "superflatten" posted at http://discussion.autodesk.com/forums/thread.jspa?threadID=601653 Quote Link to comment Share on other sites More sharing options...
e.mounir Posted December 27, 2009 Author Share Posted December 27, 2009 It is not working Quote Link to comment Share on other sites More sharing options...
tzframpton Posted December 27, 2009 Share Posted December 27, 2009 It is not working Can you give a little more info on what's happening instead of just "It is not working"? What exactly isn't working for you, the FLATTEN command? Or the link to the other routine that was posted? Quote Link to comment Share on other sites More sharing options...
lpseifert Posted December 27, 2009 Share Posted December 27, 2009 Try this... Command: move Select objects: all 19 found Select objects: Specify base point or [Displacement] : 0,0,0 Specify second point or : 0,0,1e99 Command: move Select objects: p 19 found Select objects: Specify base point or [Displacement] : 0,0,0 Specify second point or : 0,0,-1e99 Quote Link to comment Share on other sites More sharing options...
tzframpton Posted December 27, 2009 Share Posted December 27, 2009 Hey lpseifert I went searching through the help file regarding those fancy coordinate entries and I couldn't find exactly what you typed and what it meant. Can you give an explanation of what you typed, why, and how it effects the objects? I'm not understanding the "1e99" part. Quote Link to comment Share on other sites More sharing options...
lpseifert Posted December 27, 2009 Share Posted December 27, 2009 Under Units, it's Scientific (exponential notation) 1e99 means 1 times 10 to the 99th power (very large number) I think.... since these numbers are beyond acad's ability to process accurately, acad sees them as the largest number that can be processed. So the Z value + the displacement value of 1e99 essentially equals 1e99. It may have something to do with acad's precision only being 16 decimal spaces. I would imagine that some one else has a better/more accurate explanation. I learned this trick from CAB, maybe he knows. Quote Link to comment Share on other sites More sharing options...
e.mounir Posted December 28, 2009 Author Share Posted December 28, 2009 The FLATTEN command not working and also the link I do what lpseifert said but every thing go away (not display) not found in the drawing Quote Link to comment Share on other sites More sharing options...
e.mounir Posted December 28, 2009 Author Share Posted December 28, 2009 it is working fine lpseifert thanks alot Quote Link to comment Share on other sites More sharing options...
ReMark Posted December 28, 2009 Share Posted December 28, 2009 After doing what lpseifert said did you do a zoom > entents? Quote Link to comment Share on other sites More sharing options...
e.mounir Posted December 28, 2009 Author Share Posted December 28, 2009 ( Command: move Select objects: all 19 found Select objects: Specify base point or [Displacement] : 0,0,0 Specify second point or : 0,0,1e99 Command: move Select objects: p 19 found Select objects: Specify base point or [Displacement] : 0,0,0 Specify second point or : 0,0,-1e99 Quote Link to comment Share on other sites More sharing options...
pcoyote Posted April 25, 2011 Share Posted April 25, 2011 When I draw a straight line with Ortho on, it isn't straight. It has jags in it, like the drawing is slightly off Quote Link to comment Share on other sites More sharing options...
tzframpton Posted April 25, 2011 Share Posted April 25, 2011 Does it happen on every drawing or just one drawing? Quote Link to comment Share on other sites More sharing options...
pcoyote Posted April 25, 2011 Share Posted April 25, 2011 I am only working on one drawing - a large project, the only one on my new computer Quote Link to comment Share on other sites More sharing options...
tzframpton Posted April 26, 2011 Share Posted April 26, 2011 Does this error happen in a fresh drawing? Quote Link to comment Share on other sites More sharing options...
tzframpton Posted April 26, 2011 Share Posted April 26, 2011 Nvm. U got it on another post. Quote Link to comment Share on other sites More sharing options...
SuperCAD Posted April 26, 2011 Share Posted April 26, 2011 Thread necromancy! Quote Link to comment Share on other sites More sharing options...
alanjt Posted April 26, 2011 Share Posted April 26, 2011 thread necromancy! mtg! ......................... Quote Link to comment Share on other sites More sharing options...
arunz Posted May 24, 2014 Share Posted May 24, 2014 Dear Mr. e.Mounir, I have problem with z value.. I used AutoCAD LT 2014 here with attach the link can you find and explain the solution http://www.cadtutor.net/forum/showthread.php?86377-copy-paste-problem Quote Link to comment Share on other sites More sharing options...
ReMark Posted May 24, 2014 Share Posted May 24, 2014 arunz: The last viable post in this thread was three years ago. Why don't you go back to your most recent thread and continue the discussion there. FYI - The last time the forum member you are trying to address was on CADTutor was December, 2012. It's almost 18 months later. Quote Link to comment Share on other sites More sharing options...
